CTP® Versatile 4-Pin Magnetic Pogo Pin Connector Engineered specifically for everyday consumer electronics, this ultimate versatile 4 pin magnetic pogo pin connector features a highly adaptable multi-function layout. It guarantees a smooth docking experience, stable power delivery, and reliable data transfer.
Design: 4-pin multi-function layout designed for simultaneous power and data connectivity.
Performance: Reliable 2A rated current, 12V voltage, and a smooth 200-400g magnetic force for effortless mating.
Durability: Long-lasting mechanical lifespan tested up to 30,000 mating cycles.
Protection: Standard IP54 waterproof rating paired with rigorous 48-hour salt spray testing for daily protection.
The finished assembly must define the magnetic mating component, internal conductor arrangement, cable construction and the opposite-end connection as one complete electrical system.
Confirm Pin count, contact allocation, magnet arrangement, connector shape, polarity control and mating direction.
Define cable length, conductor count, wire specification, shielding requirements, jacket and flexibility.
Select USB, Type-C, DC plug, bare wire, terminal, PCB connection or another customized termination.
Confirm installation space, outlet direction, strain relief, exposed-contact state and user operation.
Our premium versatile 4 pin magnetic pogo pin connector provides the ultimate reliable power and data solution for modern lightweight consumer electronics. By integrating a highly adaptable pin layout with a carefully calibrated magnetic pull, this versatile 4 pin magnetic pogo pin connector guarantees stable performance and a remarkably smooth user experience for everyday devices.
User comfort and daily reliability are absolutely critical in consumer hardware design. That is exactly why our versatile 4 pin magnetic pogo pin connector utilizes a highly effective multi-channel structure paired with a fine-tuned 200-400g magnetic force. This specific magnetic strength ensures precise and automatic blind-mating while making it effortless for the end-user to detach the cable smoothly without dragging the device. This unique multi-function design comfortably handles a 2A rated current and 12V voltage, keeping your consumer electronics running safely and efficiently.
Furthermore, this high-performance versatile 4 pin magnetic pogo pin connector is built for daily household longevity. With an exceptional mechanical life of up to 30,000 mating cycles and an ultra-low contact resistance of ≤ 50mΩ, it guarantees efficient energy transfer without degradation over time. The standard IP54 waterproof rating combined with superior 3-5U” surface plating and 48-hour salt spray testing ensures excellent durability against dust and everyday wear and tear.
Review the detailed parameters of our industry-leading versatile 4 pin magnetic pogo pin connector below:
| Specification / Feature | Details & Parameters |
|---|---|
| Product Name | Multi-Function Versatile Magnetic Pogo Pin |
| Pin Count | 4 Pin |
| Core Selling Point | Multi-function connection (Power & Data) |
| Rated Current / Voltage | 2A / 12V |
| Contact Resistance | ≤ 50mΩ |
| Magnetic Force | 200-400g (Smooth mating) |
| Mating Cycles (Life) | 30,000 cycles |
| Waterproof Rating | IP54 |
| Surface Plating | 3-5U” |
| Salt Spray Test | 48 Hours |
| Primary Applications | Consumer Electronics |
