Get precision-engineered magnetic pogo pin connectors tailored to your projects. Direct engineering
support from China source manufacturer.
As a direct OEM/ODM source factory, CTP manufactures high-precision spring-loaded pogo pins for advanced PCB designs. Featuring incredibly low contact resistance, premium gold plating, and a mechanical lifespan of a model-specific cycle-life target validated under defined test conditions, our pins ensure stable connectivity for confined spaces.
Designed with a flat base for standard Surface Mount Technology. Ideal for high-speed automated pick-and-place PCB assembly.
Features a tail pin designed for through-hole soldering, providing maximum mechanical strength and stability against lateral forces.
Engineered with a 90-degree bent tail. Perfect for space-saving side-mounting scenarios where vertical space is heavily restricted.
Spring-loaded on both ends. This design allows for rapid, solderless board-to-board connections, ideal for modular internal stacking.
Designed to be mounted on the very edge of the PCB, providing low-profile horizontal connections for ultra-thin device housings.
Complete interconnect solutions featuring custom plastic housings pre-loaded with pogo pins, ready for plug-and-play integration.
| Parameters | CTP Engineering Details |
|---|---|
| Materials | Brass / Copper Alloy (Plunger & Barrel), Stainless Steel (Spring) |
| Plating Finishing | Premium Gold (Au) plating over Nickel (Ni) under-plating |
| Durability / Lifespan | 10,000 to 100,000+ Mating Cycles |
| Current Rating | a project-defined current range (High Current customizations available) |
| Spring Force | 30g - 150g+ (Fully customizable based on compression stroke) |
| Contact Resistance | Dynamic Resistance < 30 mΩ (Ensures signal performance validated for the defined interface) |
A: Yes. Because CTP controls the entire CNC turning and assembly process in-house, we can customize the exact working height, pin stroke, and spring force to match your PCB clearance requirements perfectly.
A: For high-volume SMT manufacturing, we supply our Flat Bottom Pogo Pins in standard Tape & Reel packaging, frequently equipped with high-temp pick-and-place caps to ensure stable automated assembly.
A: Gold plating over a nickel barrier prevents oxidation, dramatically reduces contact resistance, and ensures stable conductivity over a model-specific cycle-life target validated under defined test conditions in both power and data transmission.
Whether you need standard SMT pins or fully custom multi-pin connectors, CTP’s CNC precision machining ensures controlled quality requirements. Contact our engineering team with your drawings or specifications.
Discuss Your Project* Send us your STEP files or specs. We respond after reviewing the submitted project information.
